17 Tooth 0.6 Module 0.125 in. Round Bore Thin Steel Pinion Gear - am-2068b - migrated

17 Tooth 0.6 Module 0.125 in. Round Bore Thin Steel Pinion Gear

by AndyMark

$10.00 USD - $10.00 USD

$10.00 USD

$10.00 USD - $10.00 USD

$10.00 USD

Description
Specifications
Documentation

This gear can be used for the the pinion gear in the PG71 and PG188 gearboxes if switching the motor to a 550 class motor.
- Bore: 0.125 in. Round
- Face Width: 0.433 in. [11 mm]
- Finish: Zinc Plated
- Material: 1215 Steel
- Module: 0.6
- Pressure Angle: 20°
- Teeth: 17
- Weight: 0.008 lbs.
CAD Files
am-2068b 17T 0.6MOD 0.125 Bore.STEP
am-2068 17 Tooth Pinion Gear for PG71, 0.125 Bore.STEP
Layout Prints
am-2068b 17T 0.6MOD 20PA 0.125IN ROUND BORE GEAR.pdf
